1994 CITIZEN E32 SCREW MACHINE

Description

Comes with a IEMCA bar feeder!
Specifications
Capacity 1.25"
Power 7.5 hp
RPM 6,000 RPM
# Axis 6
Control CNC (MITSUBISHI)
Dimensions 61" x 120"
Weight 8,800 lbs

General Specifications per manufacturer's brochure
(all details must be confirmed by buyer)

No. of Controlled Axes: 6 (X1, X2, Z1, Z2, Z3 C1)
Simultaneous Six Axis Control (Three Systems)
Maximum Machining Diameter: 1.26
Maximum Machining Length: 12.6"
Spindle Speed: 130-6000 RPM
Rotary Tools:
Maximum Drilling / Threading Diameter: .393" / 5/16"
Spindle Speed: 225-4460 RPM
Back-Work:
Maximum Chucking Diameter of Back-Work Spindle:1.26"
Maximum Back-Work Length: 12.5"
Maximum Drilling / Threading Diameter: .5" / 1/2"
Back-Work Spindle Speed: 150-5000 RPM
No. of Tools Installable: 20
No. of Turret Indexes: 10 x 2 Per Turret
Tool Size: 3/4 x 3/4 x 3.5
Main Spindle Motor Drive: 7.5 HP
Power Supply: 15 KVA
Required Floor Space: 61"x 120"
Weight (Approx.): 8800 lbs.
Located in Provo, Utah.

We care about the machines we sell and want all of them to enjoy continued productive and profitable service for our remarkable customers.
Included specifications are gathered from various sources such as firsthand inspection, owner or operator interviews, manuals, and OEM research. All machinery specifications, condition and details are represented accurately to the best of our knowledge.
Confirmation by purchasing entity is recommended and encouraged prior to purchase. Price, location, and specifications are subject to change.
